Abstract branching decision base class. More...
#include <CbcBranchBase.hpp>
Public Member Functions | |
CbcBranchDecision () | |
Default Constructor. | |
CbcBranchDecision (const CbcBranchDecision &) | |
virtual | ~CbcBranchDecision () |
Destructor. | |
virtual CbcBranchDecision * | clone () const =0 |
Clone. | |
virtual void | initialize (CbcModel *model)=0 |
Initialize e.g. before starting to choose a branch at a node. | |
virtual int | betterBranch (CbcBranchingObject *thisOne, CbcBranchingObject *bestSoFar, double changeUp, int numberInfeasibilitiesUp, double changeDown, int numberInfeasibilitiesDown)=0 |
Compare two branching objects. | |
virtual int | bestBranch (CbcBranchingObject **objects, int numberObjects, int numberUnsatisfied, double *changeUp, int *numberInfeasibilitiesUp, double *changeDown, int *numberInfeasibilitiesDown, double objectiveValue) |
Compare N branching objects. | |
virtual int | whichMethod () |
Says whether this method can handle both methods - 1 better, 2 best, 3 both. | |
virtual void | saveBranchingObject (OsiBranchingObject *object) |
Saves a clone of current branching object. | |
virtual void | updateInformation (OsiSolverInterface *solver, const CbcNode *node) |
Pass in information on branch just done. | |
virtual void | setBestCriterion (double value) |
Sets or gets best criterion so far. | |
virtual double | getBestCriterion () const |
virtual void | generateCpp (FILE *fp) |
Create C++ lines to get to current state. | |
CbcModel * | cbcModel () const |
Model. | |
OsiChooseVariable * | chooseMethod () const |
void | setChooseMethod (const OsiChooseVariable &method) |
Set (clone) chooseMethod. | |
Protected Attributes | |
CbcBranchingObject * | object_ |
CbcModel * | model_ |
Pointer to model. | |
OsiChooseVariable * | chooseMethod_ |
Private Member Functions | |
CbcBranchDecision & | operator= (const CbcBranchDecision &rhs) |
Assignment is illegal. |
Abstract branching decision base class.
In the abstract, an CbcBranchDecision object is expected to be able to compare two possible branching choices.
The betterBranch() method is the crucial routine. It is expected to be able to compare two CbcBranchingObjects .
See CbcObject for an overview of the three classes (CbcObject, CbcBranchingObject, and CbcBranchDecision) which make up cbc's branching model.
Definition at line 434 of file CbcBranchBase.hpp.
CbcBranchDecision::CbcBranchDecision | ( | ) |
Default Constructor.
CbcBranchDecision::CbcBranchDecision | ( | const CbcBranchDecision & | ) |
virtual CbcBranchDecision::~CbcBranchDecision | ( | ) | [virtual] |
Destructor.
virtual CbcBranchDecision* CbcBranchDecision::clone | ( | ) | const [pure virtual] |
Clone.
Implemented in CbcBranchUserDecision, CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
virtual void CbcBranchDecision::initialize | ( | CbcModel * | model | ) | [pure virtual] |
Initialize e.g. before starting to choose a branch at a node.
Implemented in CbcBranchUserDecision, CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
virtual int CbcBranchDecision::betterBranch | ( | CbcBranchingObject * | thisOne, | |
CbcBranchingObject * | bestSoFar, | |||
double | changeUp, | |||
int | numberInfeasibilitiesUp, | |||
double | changeDown, | |||
int | numberInfeasibilitiesDown | |||
) | [pure virtual] |
Compare two branching objects.
Return nonzero if branching using thisOne
is better than branching using bestSoFar
.
If bestSoFar
is NULL, the routine should return a nonzero value. This routine is used only after strong branching. Either this or bestBranch is used depending which user wants.
Implemented in CbcBranchUserDecision, CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
virtual int CbcBranchDecision::bestBranch | ( | CbcBranchingObject ** | objects, | |
int | numberObjects, | |||
int | numberUnsatisfied, | |||
double * | changeUp, | |||
int * | numberInfeasibilitiesUp, | |||
double * | changeDown, | |||
int * | numberInfeasibilitiesDown, | |||
double | objectiveValue | |||
) | [virtual] |
Compare N branching objects.
Return index of best and sets way of branching in chosen object.
Either this or betterBranch is used depending which user wants.
Reimplemented in CbcBranchUserDecision, and CbcBranchDefaultDecision.
virtual int CbcBranchDecision::whichMethod | ( | ) | [inline, virtual] |
Says whether this method can handle both methods - 1 better, 2 best, 3 both.
Reimplemented in CbcBranchDynamicDecision.
Definition at line 480 of file CbcBranchBase.hpp.
virtual void CbcBranchDecision::saveBranchingObject | ( | OsiBranchingObject * | object | ) | [inline, virtual] |
Saves a clone of current branching object.
Can be used to update information on object causing branch - after branch
Reimplemented in CbcBranchDynamicDecision.
Definition at line 484 of file CbcBranchBase.hpp.
virtual void CbcBranchDecision::updateInformation | ( | OsiSolverInterface * | solver, | |
const CbcNode * | node | |||
) | [inline, virtual] |
Pass in information on branch just done.
assumes object can get information from solver
Reimplemented in CbcBranchDynamicDecision.
Definition at line 487 of file CbcBranchBase.hpp.
virtual void CbcBranchDecision::setBestCriterion | ( | double | value | ) | [inline, virtual] |
Sets or gets best criterion so far.
Reimplemented in CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
Definition at line 490 of file CbcBranchBase.hpp.
virtual double CbcBranchDecision::getBestCriterion | ( | ) | const [inline, virtual] |
Reimplemented in CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
Definition at line 491 of file CbcBranchBase.hpp.
virtual void CbcBranchDecision::generateCpp | ( | FILE * | fp | ) | [inline, virtual] |
Create C++ lines to get to current state.
Definition at line 493 of file CbcBranchBase.hpp.
CbcModel* CbcBranchDecision::cbcModel | ( | ) | const [inline] |
Model.
Definition at line 495 of file CbcBranchBase.hpp.
OsiChooseVariable* CbcBranchDecision::chooseMethod | ( | ) | const [inline] |
Definition at line 500 of file CbcBranchBase.hpp.
void CbcBranchDecision::setChooseMethod | ( | const OsiChooseVariable & | method | ) |
Set (clone) chooseMethod.
CbcBranchDecision& CbcBranchDecision::operator= | ( | const CbcBranchDecision & | rhs | ) | [private] |
Assignment is illegal.
Reimplemented in CbcBranchUserDecision, CbcBranchDefaultDecision, and CbcBranchDynamicDecision.
CbcBranchingObject* CbcBranchDecision::object_ [protected] |
Definition at line 508 of file CbcBranchBase.hpp.
CbcModel* CbcBranchDecision::model_ [protected] |
Pointer to model.
Definition at line 510 of file CbcBranchBase.hpp.
OsiChooseVariable* CbcBranchDecision::chooseMethod_ [protected] |
Definition at line 514 of file CbcBranchBase.hpp.
