#include <OSMatlabSolver.h>
Public Member Functions | |
| OSMatlab () | |
| the OSMatlab class constructor More... | |
| ~OSMatlab () | |
| the OSMatlab class destructor More... | |
| std::string | solve () |
| Solve the problem instance. More... | |
| void | createOSInstance () |
| Create an OSInstance. More... | |
Public Attributes | |
| SparseMatrix * | sparseMat |
| sparseMat is a pointer to an OS Sprase Matrix data structure More... | |
| double * | bl |
| bl is a pointer to the lower bounds on the constraints More... | |
| double * | bu |
| bu is a pointer to the upper bounds on the constraints More... | |
| double * | obj |
| obj is a pointer to the objective function coefficients More... | |
| double * | vl |
| vl is a pointer to the lower bounds on the varialbes More... | |
| double * | vu |
| vu is a pointer to the upper bounds on the variables More... | |
| int | numVar |
| numVar is the number of variables in the problem More... | |
| int | numCon |
| numCon is the number of constraints in the problem More... | |
| char * | varType |
| varType is a pointer to the variable type eg C, B, I More... | |
| bool | objType |
| objType indicates whether or not we have a max (1) or a min (0) More... | |
| int | numQTerms |
| numQTerms is the number of quadratic terms More... | |
| int * | qRows |
| qRows is a pointer to the row index of each quadratic term More... | |
| int * | qIndex1 |
| qIndex1 is a pointer to the index of the first variable in each of the quadratic terms More... | |
| int * | qIndex2 |
| qIndex2 is a pointer to the index of the second variable in each of the quadratic terms More... | |
| double * | qVal |
| qVal is a pointer to the coefficient value of each of the quadratic terms. More... | |
| DefaultSolver * | solverType |
| solverType is the a pointer to the sovler that will be requested More... | |
| std::string | instanceName |
| instanceName is the name of the problem instance More... | |
| std::string | sSolverName |
| sSolverName is the name of the solver More... | |
| std::string | sAgentAddress |
| is the address of the solver service More... | |
| OSInstance * | osinstance |
| osinstance is a pointer to an OSInstance object that gets created from the MATLAB data structures More... | |
| std::string | osil |
| is the osil instance that gets created from the MATLAB data structures More... | |
Detailed Description
The OSMatlab Class.
- Version
- 1.0, 03/14/2004
- Since
- OS 1.0
- Remarks
- the OSMatlab class is used by the matlabSolver mex (Matlab EXecutable) which takes MATLAB data structures and creats an OSiL string.
for now we can only handle linear integer and quadratic programming problems, not general nonlinear problems
Definition at line 49 of file OSMatlabSolver.h.
Constructor & Destructor Documentation
| OSMatlab::OSMatlab | ( | ) |
the OSMatlab class constructor
Definition at line 36 of file OSMatlabSolver.cpp.
| OSMatlab::~OSMatlab | ( | ) |
the OSMatlab class destructor
Definition at line 61 of file OSMatlabSolver.cpp.
Member Function Documentation
| std::string OSMatlab::solve | ( | ) |
Solve the problem instance.
- Returns
- a string with the solution in OSrL format
Definition at line 66 of file OSMatlabSolver.cpp.
| void OSMatlab::createOSInstance | ( | ) |
Create an OSInstance.
Definition at line 200 of file OSMatlabSolver.cpp.
Member Data Documentation
| SparseMatrix* OSMatlab::sparseMat |
sparseMat is a pointer to an OS Sprase Matrix data structure
Definition at line 63 of file OSMatlabSolver.h.
| double* OSMatlab::bl |
bl is a pointer to the lower bounds on the constraints
Definition at line 68 of file OSMatlabSolver.h.
| double* OSMatlab::bu |
bu is a pointer to the upper bounds on the constraints
Definition at line 73 of file OSMatlabSolver.h.
| double* OSMatlab::obj |
obj is a pointer to the objective function coefficients
Definition at line 78 of file OSMatlabSolver.h.
| double* OSMatlab::vl |
vl is a pointer to the lower bounds on the varialbes
Definition at line 83 of file OSMatlabSolver.h.
| double* OSMatlab::vu |
vu is a pointer to the upper bounds on the variables
Definition at line 88 of file OSMatlabSolver.h.
| int OSMatlab::numVar |
numVar is the number of variables in the problem
Definition at line 93 of file OSMatlabSolver.h.
| int OSMatlab::numCon |
numCon is the number of constraints in the problem
Definition at line 98 of file OSMatlabSolver.h.
| char* OSMatlab::varType |
varType is a pointer to the variable type eg C, B, I
Definition at line 103 of file OSMatlabSolver.h.
| bool OSMatlab::objType |
objType indicates whether or not we have a max (1) or a min (0)
Definition at line 108 of file OSMatlabSolver.h.
| int OSMatlab::numQTerms |
numQTerms is the number of quadratic terms
Definition at line 111 of file OSMatlabSolver.h.
| int* OSMatlab::qRows |
qRows is a pointer to the row index of each quadratic term
Definition at line 116 of file OSMatlabSolver.h.
| int* OSMatlab::qIndex1 |
qIndex1 is a pointer to the index of the first variable in each of the quadratic terms
Definition at line 121 of file OSMatlabSolver.h.
| int* OSMatlab::qIndex2 |
qIndex2 is a pointer to the index of the second variable in each of the quadratic terms
Definition at line 126 of file OSMatlabSolver.h.
| double* OSMatlab::qVal |
qVal is a pointer to the coefficient value of each of the quadratic terms.
Definition at line 131 of file OSMatlabSolver.h.
| DefaultSolver* OSMatlab::solverType |
solverType is the a pointer to the sovler that will be requested
Definition at line 136 of file OSMatlabSolver.h.
| std::string OSMatlab::instanceName |
instanceName is the name of the problem instance
Definition at line 139 of file OSMatlabSolver.h.
| std::string OSMatlab::sSolverName |
sSolverName is the name of the solver
Definition at line 142 of file OSMatlabSolver.h.
| std::string OSMatlab::sAgentAddress |
is the address of the solver service
Definition at line 145 of file OSMatlabSolver.h.
| OSInstance* OSMatlab::osinstance |
osinstance is a pointer to an OSInstance object that gets created from the MATLAB data structures
Definition at line 163 of file OSMatlabSolver.h.
| std::string OSMatlab::osil |
is the osil instance that gets created from the MATLAB data structures
Definition at line 168 of file OSMatlabSolver.h.
The documentation for this class was generated from the following files:
- /tmp/OS-2.10.2/OS/src/OSSolverInterfaces/OSMatlabSolver.h
- /tmp/OS-2.10.2/OS/src/OSSolverInterfaces/OSMatlabSolver.cpp
