This is the Clp interface to CoinPresolve. More...
#include <ClpPresolve.hpp>
Public Member Functions
Main Constructor, destructor
ClpPresolve ()
Default constructor. More...
virtual  ~ClpPresolve ()
Virtual destructor. More...
presolve  presolves a model, transforming the model
and saving information in the ClpPresolve object needed for postsolving. This underlying (protected) method is virtual; the idea is that in the future, one could override this method to customize how the various presolve techniques are applied. This version of presolve returns a pointer to a new presolved model. NULL if infeasible or unbounded. This should be paired with postsolve below. The advantage of going back to original model is that it will be exactly as it was i.e. 0.0 will not become 1.0e19. If keepIntegers is true then bounds may be tightened in original. Bounds will be moved by up to feasibilityTolerance to try and stay feasible. Names will be dropped in presolved model if asked
ClpSimplex *  presolvedModel (ClpSimplex &si, double feasibilityTolerance=0.0, bool keepIntegers=true, int numberPasses=5, bool dropNames=false, bool doRowObjective=false, const char *prohibitedRows=NULL, const char *prohibitedColumns=NULL)
int  presolvedModelToFile (ClpSimplex &si, std::string fileName, double feasibilityTolerance=0.0, bool keepIntegers=true, int numberPasses=5, bool dropNames=false, bool doRowObjective=false)
This version saves data in a file. More...
ClpSimplex *  model () const
Return pointer to presolved model, Up to user to destroy. More...
ClpSimplex *  originalModel () const
Return pointer to original model. More...
void  setOriginalModel (ClpSimplex *model)
Set pointer to original model. More...
const int *  originalColumns () const
return pointer to original columns More...
const int *  originalRows () const
return pointer to original rows More...
void  setNonLinearValue (double value)
"Magic" number. More...
double  nonLinearValue () const
bool  doDual () const
Whether we want to do dual part of presolve. More...
void  setDoDual (bool doDual)
bool  doSingleton () const
Whether we want to do singleton part of presolve. More...
void  setDoSingleton (bool doSingleton)
bool  doDoubleton () const
Whether we want to do doubleton part of presolve. More...
void  setDoDoubleton (bool doDoubleton)
bool  doTripleton () const
Whether we want to do tripleton part of presolve. More...
void  setDoTripleton (bool doTripleton)
bool  doTighten () const
Whether we want to do tighten part of presolve. More...
void  setDoTighten (bool doTighten)
bool  doForcing () const
Whether we want to do forcing part of presolve. More...
void  setDoForcing (bool doForcing)
bool  doImpliedFree () const
Whether we want to do impliedfree part of presolve. More...
void  setDoImpliedFree (bool doImpliedfree)
bool  doDupcol () const
Whether we want to do dupcol part of presolve. More...
void  setDoDupcol (bool doDupcol)
bool  doDuprow () const
Whether we want to do duprow part of presolve. More...
void  setDoDuprow (bool doDuprow)
bool  doDependency () const
Whether we want to do dependency part of presolve. More...
void  setDoDependency (bool doDependency)
bool  doTransfer () const
Whether we want to do transfer part of presolve. More...
void  setDoTransfer (bool doTransfer)
bool  doSingletonColumn () const
Whether we want to do singleton column part of presolve. More...
void  setDoSingletonColumn (bool doSingleton)
bool  doGubrow () const
Whether we want to do gubrow part of presolve. More...
void  setDoGubrow (bool doGubrow)
bool  doTwoxTwo () const
Whether we want to do twoxtwo part of presolve. More...
void  setDoTwoxtwo (bool doTwoxTwo)
bool  doIntersection () const
Whether we want to allow duplicate intersections. More...
void  setDoIntersection (bool doIntersection)
int  zeroSmall () const
How much we want to zero small values from aggregation  ratio 0  1.0e12, 1 1.0e11, 2 1.0e10, 3 1.0e9. More...
void  setZeroSmall (int value)
int  presolveActions () const
Set whole group. More...
void  setPresolveActions (int action)
void  setSubstitution (int value)
Substitution level. More...
void  statistics ()
Asks for statistics. More...
int  presolveStatus () const
Return presolve status (0,1,2) More...
postsolve  postsolve the problem. If the problem
has not been solved to optimality, there are no guarantees. If you are using an algorithm like simplex that has a concept of "basic" rows/cols, then set updateStatus Note that if you modified the original problem after presolving, then you must ``undo'' these modifications before calling postsolve. This version updates original
virtual void  postsolve (bool updateStatus=true)
void  destroyPresolve ()
Gets rid of presolve actions (e.g.when infeasible) More...
private or protected data
ClpSimplex *  originalModel_
Original model  must not be destroyed before postsolve. More...
ClpSimplex *  presolvedModel_
ClpPresolved model  up to user to destroy by deleteClpPresolvedModel. More...
double  nonLinearValue_
"Magic" number. More...
int *  originalColumn_
Original column numbers. More...
int *  originalRow_
Original row numbers. More...
double *  rowObjective_
Row objective. More...
const CoinPresolveAction *  paction_
The list of transformations applied. More...
int  ncols_
The postsolved problem will expand back to its former size as postsolve transformations are applied. More...
int  nrows_
CoinBigIndex  nelems_
int  numberPasses_
Number of major passes. More...
int  substitution_
Substitution level. More...
std::string  saveFile_
Name of saved model file. More...
int  presolveActions_
Whether we want to skip dual part of presolve etc. More...
virtual const CoinPresolveAction *  presolve (CoinPresolveMatrix *prob)
If you want to apply the individual presolve routines differently, or perhaps add your own to the mix, define a derived class and override this method. More...
virtual void  postsolve (CoinPostsolveMatrix &prob)
Postsolving is pretty generic; just apply the transformations in reverse order. More...
virtual ClpSimplex *  gutsOfPresolvedModel (ClpSimplex *originalModel, double feasibilityTolerance, bool keepIntegers, int numberPasses, bool dropNames, bool doRowObjective, const char *prohibitedRows=NULL, const char *prohibitedColumns=NULL)
This is main part of Presolve. More...
This is the Clp interface to CoinPresolve.
Definition at line 15 of file ClpPresolve.hpp.
ClpPresolve::ClpPresolve  (  )
Default constructor.

virtual
Virtual destructor.
ClpSimplex* ClpPresolve::presolvedModel  (  ClpSimplex &  si,
double  feasibilityTolerance = 0.0 ,

bool  keepIntegers = true ,

int  numberPasses = 5 ,

bool  dropNames = false ,

bool  doRowObjective = false ,

const char *  prohibitedRows = NULL ,

const char *  prohibitedColumns = NULL

)
int ClpPresolve::presolvedModelToFile  (  ClpSimplex &  si,
std::string  fileName,
double  feasibilityTolerance = 0.0 ,

bool  keepIntegers = true ,

int  numberPasses = 5 ,

bool  dropNames = false ,

bool  doRowObjective = false

)
This version saves data in a file.
The passed in model is updated to be presolved model. Returns nonzero if infeasible
ClpSimplex* ClpPresolve::model  (  )  const
Return pointer to presolved model, Up to user to destroy.
ClpSimplex* ClpPresolve::originalModel  (  )  const
Return pointer to original model.
void ClpPresolve::setOriginalModel  (  ClpSimplex *  model  )
Set pointer to original model.
const int* ClpPresolve::originalColumns  (  )  const
return pointer to original columns
const int* ClpPresolve::originalRows  (  )  const
return pointer to original rows

inline
"Magic" number.
If this is nonzero then any elements with this value may change and so presolve is very limited in what can be done to the row and column. This is for nonlinear problems.
Definition at line 76 of file ClpPresolve.hpp.

inline
Definition at line 80 of file ClpPresolve.hpp.

inline
Whether we want to do dual part of presolve.
Definition at line 85 of file ClpPresolve.hpp.

inline
Definition at line 89 of file ClpPresolve.hpp.

inline
Whether we want to do singleton part of presolve.
Definition at line 97 of file ClpPresolve.hpp.

inline
Definition at line 101 of file ClpPresolve.hpp.

inline
Whether we want to do doubleton part of presolve.
Definition at line 109 of file ClpPresolve.hpp.

inline
Definition at line 113 of file ClpPresolve.hpp.

inline
Whether we want to do tripleton part of presolve.
Definition at line 121 of file ClpPresolve.hpp.

inline
Definition at line 125 of file ClpPresolve.hpp.

inline
Whether we want to do tighten part of presolve.
Definition at line 133 of file ClpPresolve.hpp.

inline
Definition at line 137 of file ClpPresolve.hpp.

inline
Whether we want to do forcing part of presolve.
Definition at line 145 of file ClpPresolve.hpp.

inline
Definition at line 149 of file ClpPresolve.hpp.

inline
Whether we want to do impliedfree part of presolve.
Definition at line 157 of file ClpPresolve.hpp.

inline
Definition at line 161 of file ClpPresolve.hpp.

inline
Whether we want to do dupcol part of presolve.
Definition at line 169 of file ClpPresolve.hpp.

inline
Definition at line 173 of file ClpPresolve.hpp.

inline
Whether we want to do duprow part of presolve.
Definition at line 181 of file ClpPresolve.hpp.

inline
Definition at line 185 of file ClpPresolve.hpp.

inline
Whether we want to do dependency part of presolve.
Definition at line 193 of file ClpPresolve.hpp.

inline
Definition at line 197 of file ClpPresolve.hpp.

inline
Whether we want to do transfer part of presolve.
Definition at line 205 of file ClpPresolve.hpp.

inline
Definition at line 209 of file ClpPresolve.hpp.

inline
Whether we want to do singleton column part of presolve.
Definition at line 217 of file ClpPresolve.hpp.

inline
Definition at line 221 of file ClpPresolve.hpp.

inline
Whether we want to do gubrow part of presolve.
Definition at line 229 of file ClpPresolve.hpp.

inline
Definition at line 233 of file ClpPresolve.hpp.

inline
Whether we want to do twoxtwo part of presolve.
Definition at line 241 of file ClpPresolve.hpp.

inline
Definition at line 245 of file ClpPresolve.hpp.

inline
Whether we want to allow duplicate intersections.
Definition at line 253 of file ClpPresolve.hpp.

inline
Definition at line 257 of file ClpPresolve.hpp.

inline
How much we want to zero small values from aggregation  ratio 0  1.0e12, 1 1.0e11, 2 1.0e10, 3 1.0e9.
Definition at line 266 of file ClpPresolve.hpp.

inline
Definition at line 270 of file ClpPresolve.hpp.

inline
Set whole group.
Definition at line 276 of file ClpPresolve.hpp.

inline
Definition at line 280 of file ClpPresolve.hpp.

inline
Substitution level.
Definition at line 285 of file ClpPresolve.hpp.

inline
Asks for statistics.
Definition at line 290 of file ClpPresolve.hpp.
int ClpPresolve::presolveStatus  (  )  const
Return presolve status (0,1,2)

virtual
void ClpPresolve::destroyPresolve  (  )
Gets rid of presolve actions (e.g.when infeasible)

protectedvirtual
If you want to apply the individual presolve routines differently, or perhaps add your own to the mix, define a derived class and override this method.

protectedvirtual
Postsolving is pretty generic; just apply the transformations in reverse order.
You will probably only be interested in overriding this method if you want to add code to test for consistency while debugging new presolve techniques.

protectedvirtual
This is main part of Presolve.

private
Original model  must not be destroyed before postsolve.
Definition at line 313 of file ClpPresolve.hpp.

private
ClpPresolved model  up to user to destroy by deleteClpPresolvedModel.
Definition at line 316 of file ClpPresolve.hpp.

private
"Magic" number.
If this is nonzero then any elements with this value may change and so presolve is very limited in what can be done to the row and column. This is for nonlinear problems. One could also allow for cases where sign of coefficient is known.
Definition at line 322 of file ClpPresolve.hpp.

private
Original column numbers.
Definition at line 324 of file ClpPresolve.hpp.

private
Original row numbers.
Definition at line 326 of file ClpPresolve.hpp.

private
Row objective.
Definition at line 328 of file ClpPresolve.hpp.

private
The list of transformations applied.
Definition at line 330 of file ClpPresolve.hpp.

private
The postsolved problem will expand back to its former size as postsolve transformations are applied.
It is efficient to allocate data structures for the final size of the problem rather than expand them as needed. These fields give the size of the original problem.
Definition at line 337 of file ClpPresolve.hpp.

private
Definition at line 338 of file ClpPresolve.hpp.

private
Definition at line 339 of file ClpPresolve.hpp.

private
Number of major passes.
Definition at line 341 of file ClpPresolve.hpp.

private
Substitution level.
Definition at line 343 of file ClpPresolve.hpp.

private
Name of saved model file.
Definition at line 346 of file ClpPresolve.hpp.

private
Whether we want to skip dual part of presolve etc.
512 bit allows duplicate column processing on integer columns and dual stuff on integers
Definition at line 352 of file ClpPresolve.hpp.
